VC -1000

The video colposcope Advanced® VC-1000 with Acetic and acid iodine reaction test timer, single aperture light source, electronic green filter enhances vascular image display, integrative management of image displaying capturing, editing, saving and printing, dynamic, playback, comparison analyzing, statistic and colposcopy report.

Key Features

• Camera Pixels: 440,000 (PAL), 380,000 (NTSC)
• Magnification: 1 ~ 28 x (VC-1000); 1 ~ 36 x
• Focus: Manual, automatic
• Output signal: S-Video
• Video mode: PAL / NTSC
• Operating distance: 200 mm-300 mm
• System resolution: 500 TVL
• Space resolution: 10 lpm
• Camera lighting: Group of ring-shaped white LEDs
• Lighting: 1600 lux
• White balance: Automatic, manual
• Green light mode, white light
• SNR: 50 dB
• Scope of vision: 3X: 60 mm; 18X: 6 mm
• Depth of vision: 3X: 120 mm 18X: 5 mm
• Meet ISO 13485 Quality Standard.
• Two years warranty.

Video Colposcope
