V-1000T Plus

Multi-functional Turbine Ventilator

The Advanced® V-1000T Plus is a turbine-driven ICU and transport ventilator built for excellent performance with easy operation. Its powerful built-in turbine delivers a 240 L/min peak flow rate, while a lightweight 8.5 kg body and 1-second detachable breathing valve make it suitable for intensive care, in-hospital transport, and post-surgical recovery.

Key Features of the V-1000T Plus

• Turbine-driven, electric drive/electric control
• 240 L/min peak flow rate
• 1 s detachable breathing valve, autoclavable up to 134 °C
  360° visual alarm light
• Full touch screen, compact and easy to clean
• 8.5 kg lightweight (without battery)
• 12.1″ standard screen / 15″ optional
• Invasive ventilation: VCV, PCV, PRVC, VSV, PSV, CPAP, DualPAP, SIMV(VCV)+PS, SIMV(PCV)+PS, SIMV(PRVC)+PS, APRV
  Non-invasive ventilation: PCV, PSV, CPAP, DualPAP, SIMV(PCV)+PS, APRV
• HFNC 2.0 (single and dual tube)
• Flow Support® patient-ventilator synchrony technology
• Intelligent VSV — automatic tidal-volume adjustment
• Lung Protection & Weaning Tools: P0.1, NIF, RSBI
• Comprehensive Respiratory Mechanics — P-V tool and Stress Index (SI)
• Dynamic Lung View — compliance, resistance, spontaneous breathing status
• Communication: Wi-Fi, 3G/4G, wired network, RJ45, USB, HDMI, RS232, Nurse call
• Data connectivity with infusion pumps, ICU systems and patient monitors
• Extensible modules: SpO2, EtCO2, paramagnetic oxygen
  Battery: 120 min standard, 240 min optional (dual batteries)
• IP22 protection rating
• Noise level: no more than 45 dB(A)
