The advanced® IP-200 infusion system is a compact and comprehensive drop and volume infusion pump which can infuse fluids, medication or nutrients into a patient’s circulatory system, and it has power packed features, and provides accurate and reliable delivery over the whole range of delivery rates.

Advanced® IP-200 could be widely used for various departments of hospitals, such as medicine department, department of pediatrics, department of gynecology and obstetrics, oncology, neurology, ICU and CCU.


• Touch Screen LCD Display 4″ TFT.
• Motor-driven door and anti-leakage clip design.
• VTBI: 0.01-9999 ml.
• Flow rate range: 0.01-1200 ml/h.
• KVO Rate: 0.01-5.00 ml/h adjustable.
• The increment is 0.01 ml/h.
• Manual bolus and automatic bolus.
• Can be integrated into Docking Station.
• Database: Can record no less than 4000 history logs.
• Can record the latest 30 therapies parameters.
• Can add the edit the name of IV set brands on the pump without connect to any external devices.
• Screen Brightness is adjustable in 10 levels.
• The alarm volume is adjustable in 10 levels.
• Occlusion alarm: 4 levels adjustable .
• Pressure unit: 4 kinds selectable.
• Have the upstream pressure detection.
• The alarm information can be displayed in the form of text, sound and image at the same time.
• AC Power Supply: 220-230V / 50 – 60Hz.
• Rechargeable Lithium battery 9 hours at 25 ml/h.
• Battery capacity is showed on the screen Battery.
• Charging time : Less than 6 hours.
• Wireless LAN (optional)
• Standby function.
• Drug Library.
• Moisture protection: IP24.
• Meets ISO 13485 Quality Standard.
• Two year warranty.



Infusion Pump IP-200
